V-Tac LED Displey Outdoor P6 768/768mm | SKU 11078

• Parametri:

  Screen Parameter

  Pixel density	27777dots/sqm
  Brightness	6500nits
  Optimum view distance	more than 6m
  Gray scale	16bits
  Display color	281 trillions(synchronized)
  Operation power	220V-240V
  Max power consumption	1350W/sqm
  Control Mode	Synchronized
  Refresh Frequency	400-800HZ
  Fram Frequency	60HZ
  Surport signal input	S-Video,RGBHV,YUV etc.
  Control Distance	UTP140M,SINGLE MODE FIBER 15KM
  Operating Humidity	10%-90%
  Life span(50% brightness)	100000hrs
  IP(Front/Rear)	IP65/IP45




  LED Cabinet Parameter

  Cabinet size(L*H*D)	768*768mm
  Cabinet resolution	128*128
  Module quantity each cabinet	4*4=16
  Average power consumption	800w/cabinet
  Cabinet material	Iron
  Cabinet size	25kg/cabinet




  LED Module Parameter

  Pixel pitch	6mm
  LED specification	SMD3535
  LED configuration	SMD 3 in 1
  Module size	192*192mm
  Module resolution	32*32=1024dot
  Drive Method	1/8 scan constant current
  Drive IC	SM16106
