Fuori Produzione
SKU 11077 | Fuori Produzione V-tac
- Prezzo al pubblico: € 699,72 I. E.
- Accedi o Registrati per lo sconto a te riservato
Prodotto NON Disponibile
Caratteristiche Teniche
-
Parametri:
Screen Parameter
Pixel density 40000dots/sqm Brightness 1800nits Optimum view distance more than 5m Gray scale 16bits Display color 281 trillions(synchronized) Operation power 220V-240V Max power consumption 750W/sqm Control Mode Synchronized Refresh Frequency 400-700HZ Fram Frequency 60HZ Surport signal input S-Video,RGBHV,YUV etc. Control Distance UTP140M,SINGLE MODE FIBER 15KM Life span(50% brightness) 100000hrs IP(Front/Rear) IP20 LED Cabinet Parameter
Cabinet size(L*H*D) 640*640mm Cabinet resolution 128*128 Module quantity each cabinet 2*4=8 Average power consumption 300w/cabinet Cabinet material Iron Cabinet size 8kg/cabinet LED Module Parameter
Pixel pitch 5mm LED specification SMD3528 LED configuration SMD 3 in 1 Module size 320*160mm Module resolution 64*32=2048dot Drive Method 1/16 scan constant current Drive IC SM16106
Packaging
- EAN:3800157617475
