SKU 11812 | Inverter di Rete V-tac |
- Max. Input Power: 39kW;
- Rated Output Power: 30kW;
- Max. Active Power: 33kW;
Dimensioni 362 x 577x 215 (Excluding Connectors and Brackets)
- Prezzo al pubblico: € 1.446,25 I. E.
- Accedi o Registrati per lo sconto a te riservato
Prodotto NON Disponibile
Caratteristiche Teniche
- Series:On Grid
-
Potenza:
- Max. Input Power: 39kW;
- Rated Output Power: 30kW;
- Max. Active Power: 33kW;
-
Tensione di Alimentazione:
- Start-up DC Input Voltage: 250V;
- Max. DC Input Voltage: 1000V ;
- Nominal Output Voltage / Range: 3L/N/PE 220/380V, 230/400V;
- MPPT Operating Range: 200-850V;
-
Corrente:
- Max. DC Input Current : 40+40A;
- Max. Short Circuit Current: 60+60A
- Rated AC Grid Output Current: 45.5/43.5A
- Max. AC Output Current: 50/47.9A
- Frequenza di Input:Grid Frequency Range 45~55 or 55~65 (Optional)
- PF:0.8 lagging to 0.8 leading
- Grado di Protezione:IP65
- Condizioni di lavoro:-25~65°C, >45°C derating
- Dimensioni:362 x 577x 215 (Excluding Connectors and Brackets)
- Garanzia:5 anni
- Stato:19.06.2023
Packaging
- Peso:23 kg kg
